Release of a new HMI stencil for SCD Toolbox


The stencil is designed based on IEC 63131 and Equinor’s TR 1212 and GL 1494 and is approved to be used for development of HMI screen sketches to provide input to control system vendor and describe the appearance of HMI screens.
During the project, 25 HMI screen sketches were created by MidTechnology team using SCD Toolbox and HMI stencil. A couple of examples of the possible appearance of sketches are attached to this post.

If you are looking for ways to simplify and improve your interaction with control system vendor – contact us at scd@midt.no to implement HMI sketching approach on your project and acquire SCD Toolbox with new HMI stencil.
